Features
1.PCL control system
2.LED TFT touch screen control panel
3.Four step pitehes seleetion(10,20,30,40)
4.With the function of anti clamping plate and foolproof
5.Dircetion from left to right or right to left(option) standard
Technical parameter
| Overll dimension:1690*915*1680 |
| Special aluminum profile guide ral and special Qianniao plastic chain |
| 90W production brake motor is driven by ball screw to make Magazine step up and down |
| The feeding box transmission moto is a 15W constant speed platform motor |
| Pneumatic clamp structure |
| The specification of Magazin is(L)535°(W)460*(H)565mm |
| The maximum specification ofPCBis(L)530*(W)390mm |
| PCB storage quantity of plate sution machine:100PCS |
| Rail transmission height:920±30MM |
| Delivery direction righto left/eft to right |
| The Conveyorblt s7M flat belt |
| Conveyor transmission seed 9M/min |
| The lifting platform pitch is selected as 10,20,30,40 |
| PLC programmable controller control |
| Has the function of automatic board loading and board suction |
| The operation control panelisa display controltrue color touch screen |
| Pneumatic element (the position of push plate cylinder is adjusted by screw rod) |
| Power supply:220V 50HZ |
| Air source:0.4-0.6MPa |
